Genie Z45/25 IC Safety Decal Only
Z452507A-34011 to Z452513A-47000
2007 - 2013
This kit is based on a standard spec machine and only contains the safety decals. This kit does not contain any cosmetic or control panel decals. Please note, before ordering this safety decal kit, it is recommended that you check this sticker kit is the correct one for your machine. Please refer to a parts manual or the table below if you are unsure. We print all our safety decals and signage onto the highest quality UV protected, durable vinyl, to ensure that all decals adhere to your machines and are able to survive harsh environments.
| Part Number | Description | Qty |
| 27204GT | DECAL,ARROW BLUE | 1 |
| 27205GT | DECAL,ARROW YELLOW LRG 9" | 1 |
| 27206GT | DECAL,TRIANGLE,BLUE | 2 |
| 27207GT | DECAL,TRIANGLE,YELLOW | 2 |
| 28159GT | DECAL,DIESEL | 2 |
| 28235GT | DECAL,POWER TO PLATFORM 115V | 2 |
| 40434GT | DECAL,LANYARD ANCHORAGE POINT | 3 |
| 82240GT | DECAL,LABEL,105 DB | 1 |
| 82472GT | DECAL,WARNING,CRUSHING HAZARD | 3 |
| 82473GT | DECAL,SYMBOL-COMP ACCESS | 1 |
| 82487GT | DECAL,SYMBOL-READ THE MANUAL | 2 |
| 82544GT | DECAL,DANGER,ELEC.HAZ.STAY CLR | 3 |
| 82548GT | DECAL,WARN,CRUSH HAZARD PLAT | 2 |
| 82587GT | DECAL,HIFLOT TIRE PRESS,S40/45 | 4 |
| 82601GT | DECAL,LABEL,MAX CAPACITY*** | 1 |
| 82604GT | DECAL,DANGER,SIDE FRC 400N | 1 |
| 82633GT | DECAL,LABEL,TIRE PRESS Z45RT | 4 |
| 97815GT | DECAL,LABEL,LOWER MIDRAIL | 1 |
| 114024GT | DECAL,LABEL,WHEEL LOAD Z4525J | 4 |
| 114114GT | DECAL,LABEL,TRANSPORT | 2 |
| 114247GT | DECAL,LABEL,FALL HAZARD*** | 1 |
| 114248GT | DECAL,LABEL,TIPOVER,TILT AL SY | 1 |
| 114249GT | DECAL,LABEL,TIPOVER,TIRES,SYMB | 4 |
| 114251GT | DECAL,LABEL,NO SMOKING,SYMB | 2 |
| 114252GT | DECAL,LABEL,TIP OVER LMT SWTCH | 3 |
| 114420GT | DECAL,EMERGENCY LOWERING IC | 1 |
Control Panel Decals Not Included
| Pos. | Part Number | Description | Qty. | Comments |
| 17 | 72442GT | DECAL, GROUND CONTROL PANEL | 0 | ORDER SEPARATE |
| 19 | 82238GT | DECAL,PLATFORM CONTROL PANEL | 0 | ORDER SEPARATE |
Cosmetics Decals Not Included
| Pos. | Part Number | Description | Qty. | Comments |
| 13 | 52969GT | DECAL,COSMETIC,GENIE BOOM,HORZ | 0 |
|
| 14A | 62927GT | DECAL,COSMETIC,GENIE Z-45/25 | 0 |
|
| 15 | 62947GT | DECAL,COSMETIC,IC POWER 4 X 2 | 0 |
|
| 16 | 62948GT | DECAL,COSMETIC,IC POWER 4 X 4 | 0 |
