Genie Z45/25J DC Safety Decal Kit
PN: 823161GT
This kit is based on a standard spec machine and only contains the safety decals. This kit does not contain any cosmetic or control panel decals. Please note, before ordering this safety decal kit, it is recommended that you check this sticker kit is the correct one for your machine. Please refer to a parts manual or the table below if you are unsure. We print all our safety decals and signage onto the highest quality UV protected, durable vinyl, to ensure that all decals adhere to your machines and are able to survive harsh environments.
| Part Number | Description | Qty |
| 97815GT | DECAL,LABEL,LOWER MIDRAIL | 1 |
| 27204GT | DECAL,ARROW BLUE | 1 |
| 27205GT | DECAL,ARROW YELLOW LRG 9" | 1 |
| 27206GT | DECAL,TRIANGLE,BLUE | 2 |
| 27207GT | DECAL,TRIANGLE,YELLOW | 2 |
| 28174GT | DECAL,POWER TO PLATFORM 230V | 2 |
| 28235GT | DECAL,POWER TO PLATFORM 115V | 2 |
| 40434GT | DECAL,LANYARD ANCHORAGE POINT | 3 |
| 43658GT | DECAL, LABEL, PWR TO CHARGER 230 EU | 1 |
| 44980GT | DECAL, LABEL, PWR TO CHARGER 115 UK | 1 |
| 44981GT | DECAL,LABEL,AIRLINE 110 PSI | 2 |
| 82472GT | DECAL,WARNING,CRUSHING HAZARD | 3 |
| 82473GT | DECAL,SYMBOL-COMP ACCESS | 1 |
| 82481GT | DECAL,SYMBOL-BATTERY SAFETY | 2 |
| 82487GT | DECAL, SYMBOL - READ THE MANUAL | 2 |
| 82544GT | DECAL,DANGER,ELEC.HAZ.STAY CLR | 3 |
| 82545GT | DECAL,DANGER,MAX LOAD 227 KG** | 1 |
| 82548GT | DECAL,WARN,CRUSH HAZARD PLAT | 2 |
| 82602GT | DECAL,DANGER,MAX SIDE FRC,667N | 1 |
| 82604GT | DECAL,DANGER,SIDE FRC 400N | 1 |
| 82634GT | DECAL,LABEL,TIRE PRESS Z45DCBI | 4 |
| 82635GT | DECAL,LABEL,WHEEL LOAD Z4525DC | 4 |
Control Panel Decals Not Included
| Pos. | Part Number | Description | Qty. | Comments |
| 17 | 72444GT | DECAL, GROUND CONTROL PANEL | 0 | ORDER SEPARATE |
| 19 | 82279GT | DECAL,PLATFORM CONTROL PANEL | 0 | ORDER SEPARATE |
Cosmetics Decals Not Included
| Pos. | Part Number | Description | Qty. | Comments |
| 52969GT | DECAL,COSMETIC,GENIE BOOM,HORZ | 1 | ||
| 62068GT | DECAL,COSMETIC,BI-ENERGY | 1 | ||
| 62070GT | DECAL,COSMETIC,DC POWER | 1 | ||
| 62927GT | DECAL,COSMETIC,GENIE Z-45/25 | 1 |
