Haulotte H23TPX Safety Decal Kit, SN106423
This kit is based on a standard spec machine and only contains the safety decals. This kit
does not contain any cosmetic or control panel decals.
Please note, before ordering this safety decal kit, it is recommended that you check this
sticker kit is the correct one for your machine. Please refer to a parts manual or the table
below if you are unsure.
We print all our safety decals and signage onto the highest quality UV protected, durable
vinyl, to ensure that all decals adhere to your machines and are able to survive harsh
environments.
Part Number | Description | Quantity |
3078153210 | Floor height + load capacity for H23TPX | 2 |
3078143680 | Refer to operating manual | 1 |
3078145070 | Danger: direction of travel | 1 |
3078144570 | The plug must be connected | 1 |
3078143620 | Risk of crushing (hands and fingers) | 2 |
3078144490 | Sling load | 4 |
3078143520 | Hydraulic oil | 1 |
3078144130 | Do not park in the area in which the machine is working | 2 |
3078143600 | Do not wash... Do not use the machine... | 2 |
3078144650 | Risk of overturning : check tilt | 1 |
3078143450 | User instructions | 1 |
3078153510 | Sling fastener | 1 |
3078143590 | «High and low level» hydraulic oil | 1 |
3078143640 | Do not climb onto the hood | 1 |
3078144510 | Filling | 1 |
3078143930 | Green arrow (forwards) | 1 |
3078143940 | Red arrow (backwards) | 1 |
3078143530 | Before slewing, remove the rod | 1 |
3078143570 | Greasing of the rotation ring | 1 |
3078143630 | Risk of crushing of body | 2 |
3078149220 | Manual emergency operation assistance label | 1 |
3078153230 | Load on one wheel for H23TPX | 4 |
3078144520 | Harness | 1 |
